Making interactive
WebXR
Experiences
XR?!
- XR stands for "Mixed Reality"
- Includes AR, and VR
Augmented Reality
Augments the real world with computer graphics
There are two main AR systems:
- Marker-based systems
- Marker-less systems
Marker-based AR
Uses a visual marker to unproject the image and obtain world coordinates for the camera
Marker-less AR
Uses unique features between frames to detect camera location and mapping (SLAM)
What does WEBXR do???!
The WebXR Device API provides the following key capabilities:
- Find compatible VR or AR output devices
- Render a 3D scene to the device at an appropriate frame rate
- (Optionally) mirror the output to a 2D display
- Create vectors representing the movements of input controls
Compatibility
Compatibility
What can I use?
ARjs - link
- Built on top of JSARToolKit5
- JSARToolKit5 is a JS (Emscripten) port of ARToolkit and uses WebAssembly
- AR.js has built in support for THREE.js and AFrame
The Engine
import Scenes from './scenes';
class Engine {
constructor() {
this.times = [];
this.fps;
this.markerFound;
}
init() {
this.scene = new THREE.Scene();
this.clock = new THREE.Clock();
this.camera = new THREE.Camera();
this.scene.add(this.camera);
let ambientLight = new THREE.AmbientLight( 0x333333, 0.5 );
this.scene.add( ambientLight );
this.sunlight = new THREE.PointLight(0xffffff, 1, 100);
this.sunlight.position.set(5, 5, 5);
this.scene.add(this.sunlight);
this.renderer = new THREE.WebGLRenderer({
antialias : true,
alpha: true
});
this.renderer.setClearColor(new THREE.Color('lightgrey'), 0)
this.renderer.setSize( 640, 480 );
document.getElementById('container').appendChild(this.renderer.domElement);
this.addEvents();
this.createARProfile();
this.createARSource();
this.createARContext();
this.createARScene();
this.render();
}
addEvents() {
window.addEventListener('resize', () => this.onResize());
window.addEventListener('orientationchange', () => this.onResize());
}
onResize() {
this.arToolkitSource.onResizeElement()
this.arToolkitSource.copyElementSizeTo(this.renderer.domElement)
if ( this.arToolkitContext.arController !== null ){
this.arToolkitSource.copyElementSizeTo(this.arToolkitContext.arController.canvas)
}
}
createARProfile() {
this.arProfile = new THREEx.ArToolkitProfile();
this.arProfile.sourceWebcam();
}
createARSource() {
this.arToolkitSource = new THREEx.ArToolkitSource(this.arProfile.sourceParameters);
this.arToolkitSource.init(() => this.onResize());
}
createARContext() {
this.arToolkitContext = new THREEx.ArToolkitContext({
...this.arProfile.contextParameters,
cameraParametersUrl: '/data/camera_para.dat',
detectionMode: 'mono',
patternRatio: .75
});
this.arToolkitContext.init(() => this.camera.projectionMatrix.copy( this.arToolkitContext.getProjectionMatrix() ));
}
createARScene() {
this.sceneRoot = new THREE.Group();
this.scene.add(this.sceneRoot);
this.marker = new THREEx.ArMarkerControls(this.arToolkitContext, this.camera, {
...this.arProfile.defaultMarkerParameters,
patternUrl: '/data/pattern-ar-marker.patt',
changeMatrixMode: 'cameraTransformMatrix',
});
window.addEventListener('markerFound', () => this.markerFound = true);
window.addEventListener('markerLost', () => this.markerFound = false);
switch (window.scene) {
case 2:
this.demoScene = new Scenes.Demo2(this);
break;
default:
this.demoScene = new Scenes.Demo1(this);
}
}
update() {
// update artoolkit on every frame
if (this.arToolkitSource.ready !== false) {
this.arToolkitContext.update(this.arToolkitSource.domElement);
this.onResize();
this.sunlight.position.set(this.camera.position.x, this.camera.position.y, this.camera.position.z);
if (this.markerFound) {
this.sceneRoot.visible = true;
} else {
this.sceneRoot.visible = false;
}
this.demoScene.update();
}
}
render() {
const now = performance.now();
while (this.times.length > 0 && this.times[0] <= now - 1000) {
this.times.shift();
}
this.times.push(now);
this.fps = this.times.length;
if (document.getElementById('frameRate')) document.getElementById('frameRate').innerText = `${this.fps} FPS`;
this.update();
this.renderer.render(this.scene, this.camera);
window.requestAnimationFrame(() => this.render());
}
}
export default Engine;
Demo 1
export default class Demo1 {
constructor(engine) {
// load the assets
const gltfLoader = new THREE.GLTFLoader();
gltfLoader.load('/data/head.glb', gltf => {
gltf.scene.scale.set(.4, .4, .4);
engine.sceneRoot.add(gltf.scene);
});
}
update() {
// update the scene
}
}
Demo 1
Interactivity
Demo 2
export default class Demo2 {
constructor(engine) {
this.engine = engine;
this.touchStart;
this.touchEnd;
this.paper = [];
this.loadAssets();
this.addEvents();
}
loadAssets() {
const cylinderGeometry = new THREE.CylinderGeometry( .2, .2, .1, 16 );
const cylinderMaterial = new THREE.MeshPhongMaterial( {color: 0x00000, side: THREE.BackSide} );
this.cylinder = new THREE.Mesh( cylinderGeometry, cylinderMaterial );
this.engine.sceneRoot.add(this.cylinder);
const paperGeometry = new THREE.SphereGeometry( .1, 6, 6 );
const paperMaterial = new THREE.MeshPhongMaterial( {color: 0xFFFFFF} );
this.paperMesh = new THREE.Mesh( paperGeometry, paperMaterial );
}
addEvents() {
this.engine.renderer.domElement.addEventListener('touchstart', e => this.handleStart(e), false);
this.engine.renderer.domElement.addEventListener('touchend', e => this.handleEnd(e), false);
this.engine.renderer.domElement.addEventListener('touchmove', e => this.handleMove(e), false);
}
handleStart(e) {
e.preventDefault();
this.touchStart = {
touch: e.changedTouches[0],
time: this.engine.clock.getElapsedTime(),
}
console.log(this.touchStart);
}
handleEnd(e) {
e.preventDefault();
this.touchEnd = {
touch: e.changedTouches[0],
time: this.engine.clock.getElapsedTime(),
}
console.log(this.touchEnd);
this.paper.push(new Paper(this));
}
handleMove(e) {
e.preventDefault();
}
update() {
// update the scene
this.paper.forEach(paper => paper.update(this.engine));
}
}
class Paper {
constructor(parent) {
this.parent = parent;
this.mesh = this.parent.paperMesh.clone();
this.mesh.position.set(this.parent.engine.camera.position.x, this.parent.engine.camera.position.y, this.parent.engine.camera.position.z);
this.direction = this.parent.engine.camera.getWorldDirection().divide(new THREE.Vector3(4, 4, 4));
this.gravity = 0;
this.parent.engine.sceneRoot.add(this.mesh);
}
destroy(engine) {
this.dead = true;
engine.sceneRoot.remove(this.mesh);
}
collision(object1, object2) {
object1.geometry.computeBoundingBox(); //not needed if its already calculated
object2.geometry.computeBoundingBox();
object1.updateMatrixWorld();
object2.updateMatrixWorld();
var box1 = object1.geometry.boundingBox.clone();
box1.applyMatrix4(object1.matrixWorld);
var box2 = object2.geometry.boundingBox.clone();
box2.applyMatrix4(object2.matrixWorld);
return box1.intersectsBox(box2);
}
kill(engine) {
this.destroy(engine);
}
update(engine) {
if (this.dead) return;
this.mesh.position.add(this.direction);
this.mesh.position.z += this.gravity / 50;
this.gravity = Math.min(this.gravity + .1, 3.2);
if (this.collision(this.mesh, this.parent.cylinder)) {
console.log('collided !!');
this.kill(engine);
} else if (this.mesh.position.distanceTo(engine.camera.position) > 30) {
console.log('dying');
this.kill(engine);
}
}
}
Demo 2
What Next?
Clone the repo. Play with the code. See what you can do with it!
https://github.com/beclamide/webxr-demoThanks!
 |
